LC / PC - FC / PC Optic Patch Cord Jumper OM4 50/125um Multimode LSZH 2M Pink Jacket

Product Categories

Gezhi Photonics Co.,Ltd

Contact Now

Name: LC PC FC PC Optic Patch Cord Jumper OM4 50125um Multimode LSZH 2M Pink Jacket
Brand: GEZHI or OEM
Price: 1 USD

Brand Name : GEZHI or OEM

Model Number : GZ-Patch Cord

Certification : CE/FCC/RoHS/TUV/UL

Place of Origin : china

MOQ : 1

Price : Get Latest Price

Payment Terms : L/C, T/T

Supply Ability : 100000pcs per week

Delivery Time : 1~3working days

Packaging Details : 1pcs in a Plastic bag

Cable Jacket : LSZH

Connector : SC/PC FC/PC

Fiber Mode : OM4 50/125um

Cable Color : Pink

Length : 2meter

Fiber Count : 2fibers

Cable Diameter : 2.0mm

Net Weight : 0.03kg

Label : English

Contact Now

LC / PC - FC / PC Optic Patch Cord Jumper OM4 50/125um Multimode LSZH 2M Pink Jacket

Optical fiber jumper is used as a link between fiber optic cable and equipment wiring. It has a thick

protective layer, generally used in the connection between the transmitter and the terminal box.

Optical fiber patch cord is similar to the coaxial cable, but no net shielding layer. In multimode fiber

center is the glass core for light propagation. The diameter of the core is 50-65um, roughly equal to the

size of a person's hair. And single-mode fiber core diameter is 8-10um,

outside the core surrounded by a layer glass coating whose refractive index is lower than that of the

core in order to keep the fiber in the core. Then a thin layer of plastic jacket to protect the coating.

Features

In accordance with Telcordia GR-326-CORE standard
Low insertion loss, high return loss and high stability
Good repeated mating characteristics, good interchangeability
Using standard metal parts
Ceramic ferrule, PC, UPC, APC grinding
Can provide PVC, LSZH, OFNP, OFNR, TPU and other different colors, different outer sheath
material
Can provide G657A, G652D different fiber core material

Specifications

ptical performance	item		Test condition	Singlemode	Multimode
	Insertion loss	UPC	SM:1310/1550nm	≤0.2dB	≤0.3dB
			Mm:850/1300nm
		APC	SM:1310/1550nm	≤0.3dB
	Return loss	UPC	SM:1310/1550nm	≥55dB	≥35dB
			Mm:850/1300nm
		APC	SM:1310/1550nm	≥65dB
Mechanical loss	Compact test		1.8M height,8times	<0.1dB	<0.1dB
	Vibration test		10-60Hz, 1mm full amplitude	<0.1dB	<0.1dB
	Plug life		>1000 times	<0.1dB	<0.1dB
	Tensile strength		>100N	<0.1dB	<0.1dB
Environmental loss	High low temperature cycle test		-25~+75°C,2cycles	<0.2dB	<0.2dB
	High temperature test		+80°C,2hours	<0.2dB	<0.2dB
	Low temperature test		-40°C,2hours	<0.2dB	<0.2dB
	Damp heat test		+40°C, 90-95%RH, 2hours	<0.2dB	<0.2dB

LC / PC - FC / PC Optic Patch Cord Jumper OM4 50/125um Multimode LSZH 2M Pink Jacket
